Return Path Discontinuities Across Split Ground Planes
Routing high-speed traces across a split ground plane creates massive current loops that cause severe EMI and signal distortion.
One of the quickest ways to cause a board design to fail an EMI compliance test is to ignore the exact path your signal's return current takes. Every high-speed digital signal trace is only half of a transmission line; the other half is the return path directly beneath it on the reference plane. At frequencies above a few megahertz, return currents do not take the path of least resistance—they take the path of least inductance, meaning they mirror the signal trace precisely.
A major trap occurs when a designer uses split ground planes to isolate sensitive analog circuitry from noisy digital logic, and then routes a high-speed digital trace straight across that split gap. When the forward signal crosses the gap, the return current on the ground plane hits a physical barrier. The current cannot jump the gap, forcing it to detour around the split to find a connection point.
This detour creates a massive current loop area. This loop acts as an efficient magnetic loop antenna, radiating electromagnetic interference and causing severe signal distortion and crosstalk on adjacent traces. If you must pass a signal across a plane split, you have to provide a bridge. Place a low-ESR ceramic stitching capacitor (typically 10nF to 100nF) directly across the split, right next to the trace crossing, to give the high-frequency return current a low-impedance AC path across the gap.
